HA 780 Passenger Ferry Boat (28 PAX)


Detailed Technical  Specification


Length Overall                                    : 7.8M

Beam                                                  : 2.44 M

Draft, Maximum                                 : 0.22 M

Hull Weight                                         : 971 kg

Load (Max)                                          : 2,640 kg

Fueltank                                             : 120 LITERS

Capacity                                              : 28 Passengers + 2 Crew

Top Speed                                           : 35-60 KPH

Hull and Materials

All raw materials of the boat (General Reinforced Plastic) are approved materials for the construction of crafts by the classification society. GRP single skin (min thickness 0.821 CM)


2 x Cummins Mercruiser QSD 2.0ES 130 Horsepower diesel powered Inboard Engine

Propulsion System

Stern Drive, propeller driven.  Engine installation includes all cooling and fuel lines

Steering System

Complete Hydraulic steering system including steering wheel.


1 (one) nos 12 Volts batteries for engine ignition, with switch

Battery parallel switch for starting of main engines

1 (one) no AC/DC switchboards panel for lighting and power output on console with one spare switch

Marine type electrical cables

Main cables are laid in PVC trenching with covers

12 Volts internal lighting installed

Fuel and water level gauges with indicator on console

Switch panel with indication lights

Navigation, Search and Communication Equipment

One (1) no S.S mast for navigation lights

Two (2) nos navigation lights

One (1) no search light 100W

One (1) no single Horn

One (1) no Magnetic Compass

One (1) nos electrical wind screen wipers fixed on the glass

Mooring Equipment

Three (3) nos stainless steel mooring bollards

Two (2) nos –Mooring rope 15M X 20 MM of polypropylene marine grade

Safety Equipment

Two (2) nos Life Ring

Three (3) nos dry powder fire extinguisher, 6kg each

Thirty (30) nos Life jackets with light and whistle

Internal arrangements and Covering

Thirty (30) nos passenger seats (40 Cm width/each)


Minimum of three (3) nos windows at each side of the vessel


Heavy duty D-type rubber fender 100 MM X 100 MM around the sheer/gunwale

Four (4) nos Heavy duty rubber fender on each side of the vessel

Doors and Hatches

One (1) double door, 1M width (clearance)  at AFT with fixed safety glass window

One (1) 80 cm escape hatch in the front

Anchor, Anchor winches, Anchor chains and ropes

Stainless steel Anchor
